AHU Controller
AHU Controller, as name suggests, is designed specially to work as a Stand-alone Controller to control basic parameters such as Temperature & RH, as well filter clogging etc. of an “Air Handling Unit” (AHU). But what makes it unique is, it can be easily connected to &/ in a network and communicate with the Building Automation System on various Protocols such as PROFINET, Modbus in wired or wireless manner, at the same time, being very cost effective.
It has very precise Built-in T&RH Sensor and has a provision to add-on up to 3 differential pressure sensors. Apart from it, it has multiple Analog as well Digital Inputs and Outputs.
It has pre-programmed functions to control T&RH and display the same on a Touch Screen HMI. Other functions like Auto/Manual mode selection, setting of Alarm levels of parameters, etc. are very user friendly.
Supply Voltage:
230V AC, 50Hz
Digital Input (DI):
8 nos. 24V DC
Digital Output (DO):
4 Relay Output, NO type Plus 1 C/O Relay output for Auto/Manual Changeover.
Analog Input (AI):
6 Analogue Inputs 0-10V DC with Input Impedance => 10 M Ohms
Analog Output (AO):
4 nos. 0-10V DC
Built-in T&RH Sensor:
Temperature Range 0-50°C, Accuracy ±1% FS.
%RH Range 0-100% RH, Accuracy ±3%RH
Optional: Differential Pressure Sensors
0-1000 Pa for Fine Filter Monitoring.
0-1000 Pa for HEPA Filter Monitoring.
3.5” Touch Screen Display for system settings & alarm display.
Real Time Clock (RTC) with Battery Backup.
Ethernet Port:
10/100Mbit RJ45 Connector
PID loop:
3 nos. (T, %RH & VFD Speed)
PROFINET Interface Specifications:
Driver Type:
Class A Device
PROFINET I/O Data:
1024 bytes IN, 1024 bytes OUT
Data Transfer Rate of PROFINET:
100 Mbps
Enclosure:
278 (L) x 132 (H) x 185 (W)
Weight – 2.5 kg.
Material – ABS, IP65.
Ambient Conditions for use as well as storage:
Temperature: 0 to 75°C.
Humidity: 0 to 95 %RH Non-condensing
